Product Description

Multiquip - TP24 Tile Saw

Features:

  • 10 in. Guard, 24 in. Straight 16 in. Tile Diagonal cut
  • Compact, rugged frame assembly for easy transport, storage
  • Powerful electric motor UL/CSA approved with thermal overload protection
  • High-impact thermal plastic tray & back-splash that won't rust or bend out of shape
  • Rugged cast aluminum table with heavy-duty injection molded rubber padding. Industrial ball bearing rollers ensure smooth, precise cart movement
  • Maintenance-free submersible water pump provides high volume water flow
  • Heavy cast aluminum blade guard evenly distributes water to the blade
  • Multi-Combo rip guide and 45 degree miter block included
  • Premium 10 inch (254 mm) tile blade included
  • Optional Saw Stand (TSS) available.

Unit Specifications

  • Power Source 2 HP 115V 13A 50/60Hz
  • Blade Capacity 10 in
  • Blade RPM 3,000
  • Arbor Size 5/8 in
  • Drive System V-Belt
  • Cutting Depth 2 7/8 in
  • Straight Cut 24 in
  • Diagonal Cut 16 (Tile Size) in
  • Water Pump 115 V 100 GPH
  • Water Pan Molded Polyethylene
  • Cutting Jigs Standard

Dimensions & Weights

  • Overall Length 37 in 940 mm
  • Overall Width 26 in 660 mm
  • Overall Height 21 in 533 mm
  • Operating Weight 65 lb 29 kg



More Information

Manufacturer: Multiquip
MPN: TP24
ConditionNew
Shipping OptionsStandard Ground Shipping
