Product Description

What Makes this Engine Different?

  • Tapped 7/16-20 UNF
  • Heavy Duty Starter
  • Heavy Duty Muffler
  • 3 amp compressor spec

Features

  • Overhead Valve Design
  • Electronic Ignition
  • Quad-Clean, 4-stage, all season, heavy duty, cyclonic air cleaner
  • Dual Oil Fill Locations and Oil Drains
  • Cast Iron Cylinder Liner
  • 7 L Metal Tank w/ strainer
  • Fuel Shut-off Valve
  • Stellite Exhaust Valve
  • Oil Sentry Switch Installed (No Light)
  • Dual Ball Bearings, PTO and Flywheel
  • Balance Shaft
  • Indexable Recoil Starter
  • Large Capacity Muffler w/ Heat Shield and Spark Arrestor

Specs

Brand Kohler
Part # PA-CH440-3113
Warranty 3 Year Commercial
Shipping Weight 93 lbs.
Crankshaft Diameter 1"
Crankshaft Length 3-1/2"
Starter Type Recoil
Max RPM 3600
Displacement 429cc
Ignition System Electronic
Lubrication System Splash
Oil Capacity 1.4 qt.
Fuel Type Gasoline
Cooling System Air
Gross Torque (ft./lbs) 22.7
Cylinders 1
Bore x Stroke 3.5" x 2.7"
Crankshaft Orientation Horizontal

More Information

Manufacturer: Kohler Engines
MPN: PA-CH440-3113
ConditionNew
Shipping OptionsStandard Delivery
Oil tank volume1.4 qt.
Cylinder Displacement479
Engine CoolingAir
Engine Size14hp
Engine Type4-Stroke
# of Cylinders1
Shaft Length3-1/2"
Shaft PositionHorizontal
Shaft Width1"
Starting SystemRecoil Start
Warranty3 Year Commercial Warranty
