Kohler Engines

Kohler Command PRO 7 HP Replacement Engine 3/4 x 2-27/64 Horizontal - CH270-3011

SKU CH270-3011
$111,111.00

Kohler Command PRO CS 208cc replacement engine with a horizontal shaft measuring 3/4 in. x 2-27/64 in. with 7 hp.

Product Description

What Makes this Engine Different?

  • A Straight Keyed Shaft
  • Manual Throttle
  • Carb Tier III, EPA Phase 3 and RFI compliant

Features

  • Overhead Valve Design
  • Electronic Ignition
  • Quad-Clean, 4-stage, all season, heavy duty, cyclonic air cleaner
  • Dual Oil Fill Locations and Oil Drains
  • Cast Iron Cylinder Liner
  • 4.1 L Metal Tank w/ strainer
  • Fuel Shut-off Valve
  • Stellite Exhaust Valve
  • Engine Mounted Throttle Calbe and Chokr Controls, Remote Throttle Ready
  • Oil Sentry Switch Installed (No Light)
  • Dual Ball Bearings, PTO and Flywheel
  • Metal Blower Housing
  • Indexable Recoil Starter
  • Large Capacity Muffler w/ Heat Shield and Spark Arrestor
  • Color- Black with Cast Aluminum

Specs

Brand Kohler
Part # PA-CH270-3011
Warranty 3 Year Commercial
Shipping Weight 45 lbs.
Crankshaft Diameter 3/4"
Crankshaft Length 2-27/64"
Starter Type Recoil
Max RPM 4000
Displacement 208cc
Ignition System Electronic
Lubrication System Splash
Oil Capacity 0.63 qt.
Fuel Type Gasoline
Cooling System Air
Gross Torque (ft./lbs) 10.5 Gross Torque
Cylinders 1
Bore x Stroke 2.8" x 2.1"
Crankshaft Orientation Horizontal

More Information

Manufacturer: Kohler Engines
MPN: CH270-3011
ConditionNew
Shipping OptionsStandard Ground Shipping
Oil tank volume.63 qt.
Cylinder Displacement208cc
Engine CoolingAir
Engine Size7hp
Engine Type4-Stroke
# of Cylinders1
Shaft Length2-27/64"
Shaft PositionHorizontal
Shaft Width3/4"
Starting SystemRecoil Start
Warranty3 Year Commercial Warranty
