Kawasaki Motor Corp. USA

Kawasaki 16.5HP Engine Vertical 32.1 Max Torque FX541VDS01S

SKU FX541V-DS01S
$111,111.00

Kawasaki FX541VDS01S 603cc replacement engine with a vertical shaft measuring 1in. x 3-5/32 in. and 32.1 max torque.

Product Description

What Makes this Engine Different?

  • The Dual Stage Canister Air Filter is the biggest different between the FX541 and the FS541.
  • This engine comes without a muffler. It should be ordered seperately from the manufacturer of your mower. (If you need a muffler, feel free to call us)
  • The charging system on this engine is a clutch coil style system.

Features

  • Overhead V-Valve
  • 90º V-Twin
  • Internally vented carburetor
  • Rotating grass screen
  • Dual stage canister air filter
  • Metal engine cover

Specs

Brand Kawasaki
Part # FX541V-DS01S
Shipping Weight 89.7 lbs.
Crankshaft Diameter 1"
Crankshaft Length 3-5/32"
Starter Type Recoil
Max RPM 3600
Displacement 603cc
Ignition System Electronic Spark
Lubrication System Pressurized
Oil Capacity 1.8 qt.
Fuel Type Gasoline
Cooling System Air
Compression Release Yes
Max Torque (ft./lbs) 32.1
Oil Filter Yes
Cylinders 2
Cylinder Bore Cast Iron Liners
Bore x Stroke 2.9" x 2.8"
Crankshaft Orientation Vertical
Grade Commercial
Warranty 3 Year

More Information

Manufacturer: Kawasaki Motor Corp. USA
MPN: FX541VDS01S
ConditionNew
OEM Part #'sFX541V-DS01S, FX541VDS01S
Shipping OptionsStandard Delivery
Oil tank volume1.8 qt.
Cylinder Displacement603
Engine CoolingAir
Engine Size16.5 hp
Engine Type4-Stroke
# of Cylinders2
Shaft Length3-5/32"
Shaft PositionVertical
Shaft Width1"
Starting SystemRecoil Start
Warranty3 Year
