Product Description

Generac PD123MHB008 - DXGN14000 Portable Generator

Features:

  • Full power switch with two modes of operation - full available 120V only power or simultaneous 120/240V
  • Digital hour meter for monitoring run time and tracking maintenance
  • Broad selection of receptacles including GFCI and twistlock
  • Hydraulic/ Magnetic circuit breaker provides overload protection
  • EPA, CSA and Carb Compliant
  • Premium alternator provides low total harmonic distortion
  • Large long run metal fuel tank with fuel gauge
  • Job site tested steel frame with lifting hook
  • Idle control reduces noise and saves fuel

Product Specs:

  • Engine Brand Honda GX
  • Starting System 12-Volt Key Start
  • CC 688 CC
  • Consumer Engine Warranty 3 Years
  • Commercial Engine Warranty 3 Years
  • Engine RPM 3600 RPM
  • Low Oil Alert/Shutdown Yes
  • Cast Iron Sleeve Yes
  • Product Specs
  • Voltage 120/240 Single-Phase
  • Frequency 60 Hertz
  • Alternator Brushless
  • Auto Voltage Regulation No
  • Surge Watts 14000 Watts
  • Rated Watts 11700 Watts
  • Fuel Type Gasoline
  • Rated Amps 49 Amps
  • Portability Kit Pneumatic Wheels
  • Tank Size 10 Gallons
  • Run Time @ 50% Load 7.8 Hours
  • Fuel Tank Material Metal
  • Fuel Gauge Yes
  • Decibel Rating @ 7m 83 dbA
  • Idle Control Yes
  • Hour Meter Yes
  • Voltage Meter No
  • Lifting Eye Yes
  • Neutral Type Bonded
  • Battery Included
  • Grade Type Professional
  • Plugs
    • NEMA 5-20R - GFCI 2
    • NEMA L14-30R 1
    • NEMA 14-50R 1

Overview:

  • Assembly Required Yes
  • Weight 346 Pounds
  • Product Style Portable Generator
  • Product Length 37.5 Inches
  • Product Width 24.3 Inches
  • Product Height 31.1 Inches
  • Consumer Warranty 3 Years
  • Commercial Warranty 3 Years

More Information

Manufacturer: Generac Power Systems
MPN: PD123MHB008
ConditionNew
Shipping OptionsStandard Delivery
Amps49 A
Engine ManufacturerHonda
Frequency60Hz
HP/CC688cc
RPM3600
Starting SystemElectric Start
Voltage120/240 Single-Phase
Voltage (single phase)120 or more
Wattage14,000 W
Length37.5 Inches
Width24.3 Inches
Height31.1 Inches
WarrantyConsumer Warranty 3 Years Commercial Warranty 3 Years
